XST-MCU-SC8P1710D single-chip microcomputer semiconductor OTP ADC chip that supports C
XST-MCU-SC8P1710D
minimum order
1 piece
Quantity
- Model Number:XST-MCU-SC8P1710D
- Type:microcontroller
- Place of Origin:Guangdong, China
- Brand Name:xunster
- D/C:20221710
- Brand:microcontroller
- working current:10Ma
- quiescent current:0.3VDDV
- high level input voltage:0.1VDDV
- high level output voltage:VDDV
- low level output voltage:5.5V
- Operating voltage of the AD module:1.212V
- AD conversion error:32K
- Internal fixed reference voltage:60K
- Pull down voltage resistance:62K
- Output mouth irrigation current:35Ma
XST-MCU-SC8P171xD is a semiconductor OTP ADC chip that supports C, supports internal RC oscillations 8MHz, operating voltage 2.1V-5.5V, up to 14 GPIOs, built-in LVD modules, WDT, LCD, PWM modules, high-precision 12-bit ADC and 8-bit timer, built-in high-precision 1.2V reference voltage. The industrial standard design can work from -40°C to 85°C, and provides SOP8, SOP14 and SOP16 packages.
| symbol | parameter | test condition | minimum | typical case | maximum | unit | |
| VDD | condition | ||||||
| VDD | working voltage | - | 8MHz | 3.0 | - | 5.5 | V |
| - | 4MHz | 2.1 | - | 5.5 | V | ||
| Idd | working voltage | 5V | ADC enable | - | 2 | - | Ma |
| 3V | ADC enable | - | 1 | - | Ma | ||
| Istb | working current | 5V | - | - | 0.1 | 10 | Ma |
| 3V | - | - | 0.1 | 5 | Ma | ||
| Vil | quiescent current | - | - | - | - | 0.3VDD | V |
| Vih | - | - | 0.7VDD | - | . | V | |
| Voh | low level input voltage | - | No load | 0.9VDD | - | - | V |
| Vol | high level input voltage | - | No load | - | - | 0.1VDD | V |
| Vadi | high level output voltage | - | - | 0 | - | VDD | V |
| Vad | low level output voltage | - | - | 2.7 | - | 5.5 | V |
| Ead | The AD port input voltage | - | - | - | +2 | - | - |
| Vref | Operating voltage of the AD module | - | - | 1.188 | 1.2 | 1.212 | V |
| Rph | AD conversion error | 5V | - | - | 32 | - | K |
| Internal fixed reference voltage | 3V | - | - | 60 | - | K | |
| Rpl | Pull down voltage resistance | 5V | - | - | 34 | - | K |
| 3V | - | - | 62 | - | K | ||
| Iol | Output mouth irrigation current | 5V | Vol=0.3VDD | - | 35 | - | Ma |
| 3V | Vol=0.3VDD | - | 15 | - | Ma | ||
| Ioh | The output port pulls the current | 5V | Voh=0.7VDD | - | 17 | - | Ma |
| 3V | Voh=0.7VDD | - | 6 | - | Ma | ||
