XST-IGBT-CMS6971 bipolar Transistor semiconductor diodes transistor
XST-IGBT-CMS6971
minimum order
1 piece
Quantity
- Model Number:XST-IGBT-CMS6971
- Type:Other
- Place of Origin:Guangdong, China
- Brand Name:xunster
- Package Type:Surface Mount
- Supplier Type:Agency
- Media Available:datasheet
- 5V power supply voltage:40V
- Driving power supply voltage:40V
- LDO Output voltage:6V
- LDO Output current:100mA
- High side output voltage:2V
- Low side output voltage:12V
- Logic input voltage:6V
- Maximum power consumption (Note 1):1.4W
- Junction temperature:150℃
- ESD (Note 2):2000V
Xst-igbt-cms6971 integrates 5V LDO with load capacity of 60mA, which can supply power for internal logic of the chip and external MCU. The chip integrates various protection functions such as undervoltage protection, input direct protection and startup protection, and has a built-in dead time of 300ns, which can effectively protect the normal operation of the system. The external P / NMOS power transistor can be well driven by outputting 11V driving voltage and matching excellent leakage current capability.
| (TA = 25 ℃, VM = 12V, nu = NV = NW = GND, all pins take GND as the reference point, unless otherwise specified) | ||||||
| parameter | Symbol | Test conditions | minimum value | Typical value | Maximum | Company |
| Power supply current parameters | ||||||
| VBB Quiescent current | IBBQ | VHIN=VLIN=0 | - | 400 | - | uA |
| VBB Dynamic current | IBBD | fLIN=20kHz | - | 1.4 | - | uA |
| Power supply voltage parameters | ||||||
| VCC Undervoltage high level potential | VBBHY+ | - | 8.5 | - | V | |
| VBB Undervoltage low level potential | VBBHY- | - | 8 | - | V | |
| VBB Undervoltage hysteresis level | VBBHY | - | 0.5 | - | V | |
| Time parameter | ||||||
| When the rising edge of the output is transmitted | ton | No Load | - | 200 | - | ns |
| Output falling edge transmission time | toff | No Load | - | 200 | - | ns |
| HO Output rise time | Trise_H | CL=1nF | - | 60 | - | ns |
| HO Output falling time | Tfall_H | CL=1nF | - | 200 | - | ns |
| LO Output rise time | Trise_H | CL=1nF | - | 170 | - | ns |
| LO Output falling time | Tfall_H | CL=1nF | - | 55 | - | ns |
| Dead Time | DT | No Load | - | 300 | - | ns |
| High and low side matching time | MT | TON & TOFF | - | - | 50 | ns |
