Electronic Component XST-HE-SL106C Hall Effect Sensor Integrated Circuit XST-HE-SL106C Hall Sensor GaAs Hall Element
XST-HE-SL106C
minimum order
1 piece
Quantity
- Model Number:XST-HE-SL106C
- Type:hall effect switch
- Place of Origin:Guangdong, China
- Brand Name:Xunster
- Usage:Magnetometer Sensor Module
- Theory:Magnetometer Sensor Module
- Output:Magnetometer Sensor Module
- Description:Magnetometer Sensor Module
| Symbol | Description | Limit | Unit | Conditions |
| Vc | Max.Input Voltage | 8 | V | Ta=25℃ |
| Pd | Max.Input Power | 150 | mW | |
| Topr | Operating Temperature Range | -40~125 | ℃ | |
| Tstg | Storage Temperature Range | -40~130 | ℃ |
| Symbol | Item | Min. | Typ. | Max. | Unit | Conditions |
| Vh | Output Hall Voltage | 55 | - | 75 | mV | B=50mT, VC=6V |
| Rin | Input Resistance | 650 | - | 850 | Ω | B=0mT, Ic=0.1mA |
| Rout | Output Resistance | 650 | - | 850 | Ω | B=0mT, Ic=0.1mA |
| Vos (Vu) | Offset Voltage | -11 | - | 11.0 | mV | B=0mT, Vc=6V |
| αVh | Temp. Coefficient of Vh | - | - | -0.06 | %/℃ | B=50mT, Ic =5mA Ta=25~125℃ |
| αRin | Temp. Coefficient of Rin | - | - | 0.3 | %/℃ | B=0mT, Ic =0.1mA Ta=25~125℃ |
| ΔK | Linearity | - | - | 2 | % | B=0.1/0.5T, Ic =5mA |
