JUC31F 65CH Normally Open Temperature control switch thermal overload protector Controller Protector

• Place of Origin:Guangdong, China
• Brand Name:Xunster
• Model Number:XST-JUC-31F 800
• Type:Other
• Application:thermal overload protector
• Brand:juc31f Temperature control switch
• Operating Temperature:-55℃~180℃
• Current Rating (Amps):1A
• Voltage Rating - AC:120V
• Voltage Rating - DC:220V
• Current - Switching:1A (AC/DC)
• Series project:BL-WK-JUC-31F
• Operating Voltage/Currente:AC120V/1A DC 48/1A 220V/1A
• Contact Type:D(Normally Closed) H(Normally Open)
• Ambient Temperature:-55℃~180℃
• Over Heat Temperature:250℃ (instantaneous)
• Weight:2g
• Dielectric Strength:>AC1500V
• Insulation Resistance:>100MΩ
• Contact Resistance:≤50mΩ
• Life Cycles:≥10,000

XST-WK-JUC-31F thermal protector contact with the products for the sudden-jump temperature plastic thermostat. Adoption of interational T0220/Y220 standard package, high product reliability,samll size,light weight,easy to install ect.
