Adjustable Snap Action Temperature Sensor Switch KSD301 Thermal Switch 125V 250V 10A 16A KSD Thermostat

• Place of Origin:Guangdong, China
• Brand Name:xstsensor
• Model Number:XST-301-KSD301
• Type:Other
• Application:Electric heater
• Supplier Type:Other
• Media Available:Other
• Brand:KSD301 Thermal Switch
• Operating Temperature:-25℃- +300℃
• Current Rating (Amps):10A/16A
• Voltage Rating - AC:125V/250V
• Voltage:250V
• D/C:301-KSD301
• Series project:BL-WK-301/KSD301
• Operating temperature range:-10~300℃ (optional)
• temperature accuracy:±5℃
• According to the nature of action:Normally closed/opened
• Temperature difference:8~100℃(optional)
• Material:Electric body and ceramic body
• Contact resistance:≤50mΩ
• Enclosure protection level:IP00
• Cycle lifetime:≥10000 times

BL-WK-HKW301 series products are temperature controllers which use bimetal as temperature sensing component. 1. When the electrical appliance works normally, bimetal is in a free state, and the contacts are in a closed/open state. When the temperature reaches the operating temperature, bimetal is heated to generate internal stress and act quickly, opening/closing the contacts and cutting/connecting the circuit, thus playing a role in temperature control. When the electrical appliance is cooled to the reset temperature, the contacts will automatically close/open and return to the normal working state. 2: Manual reset requires pressing the reset button to restore the circuit.
