ZE14-O3 Ozone O3 Gas Sensor Module 0-100ppm ZE14 O3 For Ozone Concentration Detection Disinfection Cabinet
XST-ZE14
minimum order
1 piece
Quantity
- Model Number:XST-ZE14
- Type:Air quality sensor, Gas Sensor
- Place of Origin:Guangdong, China
- Brand Name:Xunster
- Usage:Ozone Concentration Detection Disinfection Cabinet
- Description:Ozone O3 Gas Sensor Module
- Target Gas:Ozone (O3)
- Interference Gas:NO2,CL2&etc.
- Output Data:UART Output
- Working Voltage:5±0.1V DC
- Warm up time:180s
- Response time:≤90s
- Detection Range:0~100ppm
- Operating Hum.:15%RH-90%RH
- Storage temperature:-20℃ ~ 65℃
- Working life:2 years (in air)
Profile
ZE14-O3 is a general-purpose and miniaturization electrochemical Ozone detection module. It utilizes
electrochemical principle to detect ozone in air which makes the module with high selectivity and stability. It is a combination of mature electrochemical detection principle and sophisticated circuit design.
Features
High sensitivity and resolution, low consumption, long life
UART output
Detection range: 0~100ppm
Applications
Ozone disinfection cabinet, smart home devices &etc.
| Model No. | ZE14-O3 |
| Target Gas | Ozone (O3) |
| Interference Gas | NO2,CL2&etc. |
| Output Data | UART Output (3V Electrical Level) |
| Working Voltage | 5±0.1V DC |
| Warm up time | 180S |
| Response time | ≤90S |
| Resume time | ≤90S |
| Detection Range | 0~100ppm |
| Resolution | 0.1ppm |
| Operating Temp. | -10℃~65℃ |
| Operating Hum. | 15%RH-90%RH (No condensation) |
| Storage temperature | -20℃ ~ 65℃ |
| Working life | 2 years (in air) |
