KSD 9700 BW KW Ceramic series snap action type bimetallic thermal cutoff switch thermostat temperature control protector
XST-WK-9700 Ceramic Edition
minimum order
1 piece
Quantity
- Place of Origin:Guangdong, China
- Brand Name:Mulsens
- Model Number:XST-WK-9700 Ceramic Edition
- Warranty:3months-1year
- Type:SNAP ACTION TYPE
- Voltage:AC 250V 5A/10A/16A
- Customized:Yes
- Whether the smart:NO
- Rated electrical parameter:AC 250V 5A/10A/16A
- Certification:CQC/UL/TUV
- action temp:15℃~165℃
- reset temp:3℃~125℃
- Tensile test:≥20N,No breaks or slips out of the wire
- Contact resistance:≤50mΩ
The 9700 ceramic shell series thermal protector uses bimetallic sheets with a certain geometric shape, without the need for auxiliary mechanisms. It relies solely on the self sensing temperature and current thermal effect of the bimetallic sheets to quickly change the state of the bimetallic components, directly driving the contacts to automatically cut off and connect the circuit, providing overheating and overload protection.
Rated electrical parameters | AC 250V 5A/10A/16A |
Action temperature | 15℃～165℃ |
Reset temperature | 3℃～125℃ |
insulation resistance | >100 MΩ |
contact resistance | ≤50mΩ |
