Electrochemical Sensors Module CH20 Formaldehyde Sensor Home Decoration Gas air quality Sensor

• Model Number:XST-ZE08B
• Place of Origin:Guangdong, China
• Brand Name:Xunster
• Usage:Air purifier
• Output:UART output
• Brand:Electrochemical CH2O Detection Module
• Voltage - Supply:3.7V~5.5V
• Operating Temperature:0℃~50℃
• Humidity Range:15%RH-90%RH
• Acceleration Range:none
• Sensitivity (LSB/g):none
• Sensitivity (mV/g):none
• Sensitivity (LSB/(°/s)):none
• Sensitivity (mV/°/s):none
• Voltage - Output Difference (Typ) @ Distance:none
• Voltage - Output (Typ) @ Distance:none
• Voltage - Rated:none
• Flow Sensor Type:none
• Voltage - Input:none
• Application:none
• Output Function:none
• D/C:none
• Cross Reference:none
• Target Gas:CH2O
• Interference Gas:Alcohol, CO &ect.
• Warm up time:≤3 minutes
• Response time:≤60s
• Detection Range:0~1.6ppm
• Resolution:≤0.01ppm
• Storage temp.:0~25℃
• Working life:2 years (in air)

Profile
ZE08B-CH2O is a general-purpose and miniaturization electrochemical formaldehyde detection module. It utilizes electrochemical principle to detect CH2O in air which makes the module with high selectivity and stability. It is built-in temperature sensor to make temperature compensation. It has the digital output and analog voltage output at the same time. It is a combination of mature electrochemical detection principle and sophisticated circuit design.

Features
High sensitivity &resolution, Low power consumption, Long life
UART output
Good stability, excellent ability of Anti-interference
Temperature compensation, Excellent Linear output

Main Application
Portable detector, air-quality monitor, air cleaner, air renewal system, air conditioner, smart home.
